Inspec.x L 4/60
최대개방시에도 높은 해상력을 제공하는 고성능 Large format 렌즈



The inspec.x L 4/60 and 4/100 are optimized for the use from infinity down through magnifications of around 0.2x. In this range these lenses show exceptional contrast over a large sensor size of up to 70 mm. High contrast goes along with very good color correction and low distortion. Especially the 60 mm lens provides unusually high performance for such a short focal length and enables imaging of large objects in space constrained environments with large sensors.

Both lenses feature a threaded interface to use them with the popular Modular Focus helical mount that provides access to virtually all existing cameras via different camera adapters.

Key features

- High contrast for small magnifications

- Excellent color correction

- Focal length: 60 and 100 mm

- Magnification range: 0 ... -0.2

- Image circle: up to 70 mm

- Spectral range: 400-750 nm

- Iris diaphragm: manual, continuous with set screw

- Mount: compatible to Modular Focus

- Wide range of mechanical accessories

광학계산기

Large format 렌즈의 배율, F/# 입력을 통해

유용한 정보를 얻을 수 있습니다.



1) Back Focal Length

2) Working Distance

3) Total Track

4) DOF

주요 사양

Family Inspec x. L
Partnumber 0019-002-000-50
Magnification range 0.2 ~ ∞ x
Magnification 0.033 x
Image circle 70.9 mm
Focal length 60.6 mm
F/#
Wavelength Visible
Type Fixed focal length
Mount M45
Maker Qioptiq

다운로드

구분 파일명 다운로드
카달로그 [2024년] 앤비젼 전제품 카달로그 다운로드
데이터시트 Inspec.x L 4/60 Datasheet 다운로드
3D 도면 Inspec.x L 4/60 Lens 3D model (STEP) 다운로드
