1) 5Gbps bandwidth USB3.0 interface
2) 256MB on-board frame buffer
3) Support multiple image data formats
4) Conform to CE, FCC, RoHS certifications
5) Software trigger/Hardware trigger/Free run mode
6) Conforms to USB 3.0 vision protocol and GenlCam standard
Family | iRAYPLE |
---|---|
Partnumber | A7A21MU200E |
Resolution | 12.6 Megapixel |
Resolution(H*V) | 4096 x 3072 pixel |
Sensor | On-Semi XGS 12000 |
Sensor size(Image Circle) | 16.38 mm |
Sensor Format(Inch) | 1" |
Turbodrive Frame Rate | |
Frame Rate | 28.6 fps |
Pixel Size | 3.2 μm |
Interface | USB3.0 |
Chroma | Mono |
Readout Method | Global |
Dynamic Range | 70 dB |
Sensor type | CMOS |
Mount | C |
Size | 29 x 44 x 58 mm |
Maker | Huaray |
