- Very high optical image quality in the large sensor range
- Vibration-insensitive for stable optical performance
- Reverse position of the lens possible to enlarge the magnification range
- Lockable distance and aperture settings

Large format 렌즈의 배율, F/# 입력을 통해
유용한 정보를 얻을 수 있습니다.
1) Back Focal Length
2) Working Distance
3) Total Track
4) DOF
| Family | PYRITE |
|---|---|
| Partnumber | 1097303 |
| Magnification range | 0.04 ~ 0.33 x |
| Magnification | 0.1 x |
| Image circle | 100 mm |
| Focal length | 102.34 mm |
| F/# | 5.6 ~ 64 |
| Wavelength | Visible |
| Type | Fixed focal length |
| Mount | V38 |
| Maker | Schneider |
