- MF5001C
- Excellent performace lens from 0.08x-0.25x
Features of Products
- For high resolution of 6576×4384 pixel
- Excellent optical performance
- Fit for 4k line scan camera
주요 사양
| Family | Large Format Fmount |
|---|---|
| Partnumber | MF5001C |
| Focal length | 50 mm |
| Image circle | 43 mm |
| Sensor Format(Inch) | |
| F/# | 2.8 ~ 22 |
| Iris Option | |
| Mount | F |
| MOD | 524.4 mm |
| Distortion | 0.2 % |
| Magnification range | 0.02 ~ 0.10 x |
| Magnification | - x |
| Wavelength | Visible |
| Type | Fixed focal length |
| Maker | Chiopt |
| Resolution |
