- Support 10 MP 4/3” camera
- Focus and iris locking screw to ensure stable focusing
- Low distortion, sharp image
- Compact structure, excellent optical performance
간단한 입력을 통해 C-mount 렌즈 관련
유용한 정보를 얻을 수 있습니다. (로그인후 사용가능)
1) Focal Length
2) Working Distance
3) FOV
Family | Pomeas |
---|---|
Partnumber | PMS-35XC10M |
Focal length | 35 mm |
Image circle | 21.3 mm |
Sensor Format(Inch) | 4/3'' |
F/# | 2 |
Iris Option | |
Mount | C |
MOD | 200 mm |
Distortion | <-0.23 % |
Magnification range | |
Magnification | |
Wavelength | - |
Type | Fixed focal length |
Maker | Pomeas |
Resolution | 10MP |
구분 | 파일명 | 다운로드 |
---|---|---|
카달로그 | [2025년] 앤비젼 전제품 카달로그 | ![]() |
데이터시트 | PMS-35XC10M Datasheet | ![]() |
