- Macro CCD 렌즈 0.14x
- 1/2“ 2/3“ C-Mount CCD 카메라를 위한 설계
Macro Lenses developed by Rodenstock Präzisionsoptik for CCD Cameras, feature the highest resolution, excellent contrast, color neutrality and are virtually free of distortions. A large selection of Macro Lenses with magnification ratios from 1:3 to 4:1 is available which can be supplied with various fixed diaphragm aperture settings.
Key Performance
- High optical performance
- Huge range of magnifications available
- Designed for 1/2" and 2/3" sensors
- Image circle: 11 mm
주요 사양
| Family | Macro CCD |
|---|---|
| Partnumber | 0009-189-000-40/ 0009-189-000-41/ 0009-189-000-42 |
| Focal length | 14.9 mm |
| Image circle | 11 mm |
| Sensor Format(Inch) | 0 |
| F/# | 4 |
| Iris Option | Fixed |
| Mount | C |
| MOD | 90 mm |
| Distortion | |
| Magnification range | 0.13 ~ 0.15 x |
| Magnification | 0.14 x |
| Wavelength | 400 ~ 750 |
| Type | Fixed focal length |
| Maker | Excelitas |
| Resolution | None |
