ENVISON

Spectrum	SWIR
Type	Area
Family	NIRvana
Partnumber	NRL-640
Resolution	0.3 Megapixel
Resolution(H*V)	640 x 512
Sensor size (Image Circle)	16.4 mm
Frame/Line Rate	2.77
Pixel Size	20 μm
Interface	GigE
Spectral Response	850 ~ 1600nm
NETD
Sensor type	2D InGaAs FPA
Operating Temp	0 ~ 30 °C
Temp. Accuracy	±0.05°C across entire temperature range
Mount	F
Lens Focal Length
Lens F/#
HFOV
Size	206.5 x 297.2 x 295.3 mm
Mass	7
Responsivity
Full Well	400 ke⁻
Dynamic Range
Quantum Efficiency	80 %
Maker	Teledyne Princeton Instruments
