Imaging Solution R&D

Imaging R&D Solutions for Inspection
Optimal development processes and infrastructure
for highest image quality

Objectives of R&D Solutions

  • Development of new optical technology based on a technical roadmap
  • Development of customized optical modules based on the voice of the customer
  • Find solutions to customer’s unresolved imaging inquiries
Development Process
Envision is equipped with systematic processes to
find the best imaging solutions.
Finding optimal solutions for unresolved imaging tasks
VOC CTQ 1)

1) Critical To Quality

SPL2) characteristics/
Manufacturing process
examination

2) Sample

Get test
SPL

SPL
Analysis

DOE3)
establishment

3) Design of experiments

Experiment

Feasibility
Test

Development Infrastructure
Based on a wide range of in-house development infrastructure,
Envision finds prompt and precise solutions.
Development equipment
Multi-axial (8-axes) optics to find the best imaging system
Evaluation equipment

In addition to the above equipment, the company has a wide range of solution equipment (such as high precision measuring equipment for acquiring images up to submicrons and an E-VIMS for capturing images between 2㎛ and 10㎛) to minimize customers’ risk in equipment components and provide consulting to suggest the best system components and solutions.

Laser confocal microscope capable of measuring heights in nano-meters
Camera performance evaluation system
E-VIMS for capturing images between 2㎛ and 10㎛
Optical instrument design/ simulation
