FA0802D
High performance for 5 Mega pixel camera

Features of Products

- nomo-focal for best image quality

- High performace for 5 Mega piexl camera

- Large aperture ratio for low illumination

- Free distortion less than 1%

- Focus range from 0.1M to Infinity

- Higher relative illuminate rate at corner

주요 사양

Family 2/3" 5Mega FA
Partnumber FA0802D
Focal length 8 mm
Image circle 11 mm
Sensor Format(Inch) 2/3''
F/# 1.4 ~ 16
Iris Option Variable
Mount
MOD 100 mm
Distortion <1 %
Magnification range 0.009 ~ 0.075 x
Magnification
Wavelength
Type
Maker Chiopt
Resolution
